ShackMaster Power 600

Compact Desktop 40A|13.8V Power Supply by RigExpert

Rated power: 500W
Rated current: 40A
Output voltage: 12.5-15 V
Input voltage range: 80V to 264V
Input frequency range: 47 Hz to 63 Hz
Working temperature range: -30°C to +70°C
Acoustic noise: ~21 dBa
Overvoltage protection: Yes
Overcurrent protection: Yes
Short circuit protection: Yes
AC current: 5,. А @ 110 VAC | 2.9 А @ 230 VAC
EMC Emission: Class I: Class B, Class II: Class A
EMI noise: 200mVp-p
Storage temperature range: -40°C to +85°C / -40°F to +185°F
Energy Conversion Efficiency (ECE): > 90% (Heat dissipation at maximum load < 60 W)
Ports on the front panel
 2 x 3A USB A Charging Ports
 2 x 3A USB Type-C Charging Ports
 2 x 45A Anderson Power Poles
Ports on the rear panel
 1 x 30A Binding Post
 1 x 45A Anderson Power Pole
 1 x USB Type-C for PC Communication
Dimensions: 172 mm x 55 mm x 185 mm
Weight: 1.1 kg

Warranty:  Manufacturer's 2-year limited warranty coverage
